Description:
Free Delivery On This Trailer in Lower 48 States at Listed Price (Offer Ends 7/31/24)
First Glance
2024 Year Model by Lakota
5 Horse
Charger Model #C8513SRT
13’ Short wall with slide out
Dinette in slide with sofa on drop down wall
Mangers, hay pod, LP Onan Generator on roof
8’ wide x 7’10” tall x 36’ long deck
17.5” Aluminum wheels with 16 ply tires
Onan 4k Gas Generator
Haypod
6 year warranty on frame, 2 year warranty on LQ, 1 year hitch to bumper on workmanship
Horse Trailer Specs
2024 year model
Manufacturer: Lakota
All aluminum (floor, sides, roof, & frame). Pre painted white aluminum skin on top and aluminum slats on bottom
8’ wide x 36’ long box x 7’10” tall
Drop down windows on head wall (5)
Drop down window bars on head wall (5)
Drop down windows on rump (4) (PC side load)
Oversized sliding bus window on load door (1)
Stainless steel wrap on nose
4 mangers with 4 access doors 22” deep
3 – 7,000 lb rubber torsion axles
Electric brakes on both axles
GVWR weight: 21,000 lbs
17.5” Aluminum Wheels
215/ 75R17.5 Sailun Tire 16 ply radial tires
Rubber dock bumper
Escape door on street side with fold down step and camper latch
4 dividers – front has removable stud panel- all spring loaded
Flow thru air dividers on head
Stall width measurements (wall measurements) 40”-39”-39”-39”-48”
Walls rubber lined
Rubber mats
Divider pads
Insulated and lined ceiling in horse compartment
3 cargo lights in horse compartment
5 pop up roof vents
4 Load lights –2 on back of trailer, 1 curb side, 1 street side
16’ Power Awning on curb side
42” opening on load door
Full Rear tack includes: 5 tier adjustable saddle rack, 20 hooks, 2 blanket bars and brush tray’s on both door
Big Foot Double Leg Hydraulic jacks
3-12Volt batteries in tray under nose
2 20 Lb LP Tanks
7 way RV light plug, 2 5/16” Coupler, safety chains, and emergency brake system
Hay pod with telescoping fold out ladder
4.0 Onan Gas Generator in compartment on roof
Living Quarter Specs
13’ LQ Conversion by Lakota w/ flush floor slide out
Slide contains oversized dinette 74” long x 46” wide
Templer Abby Interior
Insulated floor
RVIA Certified
2 40 Lb Liquid Propane (LP) tanks mounted under enclosed neck
3 - 12 volt house batteries
Panel walls and penel ceiling
Simulated hardwood linoleum floor
Day night shades on all windows
70” sleeper sofa x 41” wide when out (on drop down wall)
74” x 46” dinette sleeper in slide (storage underneath)
Queen mattress w/ dropped nose in bedroom for extra headroom (38” height from floor to ceiling in nose)
32” Jensen flat screen tv in LQ w/ DVD/AM/FM/CD player
Jensen AM/FM/CD player w/ USB port
2 burner cook top with by Suburban
High Pointe Microwave
Oversized Kitchen sink
6.0 Dometic 2 way refrigerator (LP or 110 Volt)
2 windows in nose, 1 window in slide, 1 window on curbside
Power TV antennae
15,000 BTU air conditioner ducted
20,000 BTU Ducted LP furnace
Digital thermostat
6 gallon hot water heater (LP) w/ start switch in LQ
Fresh water tank
Pocket door into bathroom
32” Neoangle Shower with skylight
Dometic toilet
Power Vent in ceiling of bathroom by Maxfan
24” Walk through door in bulkhead wall
Safety systems: LP detector, Carbon monoxide detector, and fire extinguisher
16’ Power awning and exterior speakers
Black and gray tanks with monitor system in LQ (35 gallons each)
4.0 Gas Onan Generator on roof
Black painted exterior accessories including air conditioner cover, tv antennae, refrigerator vents, & hot water heater panel
Closets/storage include: hanging closet under TV, overhead cabinets above dinette and above sofa, 2 pantry cabinets, 2 drawers in kitchen, clothes hamper behind toilet, hanging clothes rod above hamper
